WEATHER PROOF FLOOD LIGHT
PRODUCT SPECIFICATIONS & APPLICATION
Characteristics
IP rating: IP65
Isolation: Input Output Fully Isolated
Startup: Quick start < 500mS
Protection: Under & over voltage protection
HPF, High brightness, Flicker free
Color & Lighting
LED Colour: 6500K
Lumens: 110Lm/W
Beam angel: 120˚
CRI: >=80%
Operative conditions
Temperature: Ambient temperature
Humidity: up to 80%
Electrical Parameters
Power Range: 50W, 100W, 150W
Input Voltage range: AC 100V…265V
Surge Protection: Up to 6kV
Power Factor: >= 0.98
THD: <= 10%
Electrical Connection
Build in Connectors or cable
Input side: Three wire (P~N~E) for 230V AC
Output side: Connect with led
Controls
Dimming mode: No Dimming
Interface: No Interface
Mechanical Construction
Dia cast housing with Borosilicate Glass
Adjustable Handle for fitting
Dimension: Refer TDS
Weight: NA
Applications & Examples
Offshore
Tunnel, Cave
Railway Station, Bus Station
Pharma Industries
Chemical Industries
