WEATHER PROOF TUBE LIGHT

WEATHER PROOF

WEATHER PROOF TUBE LIGHT

PRODUCT SPECIFICATIONS & APPLICATION

Characteristics

IP rating: IP65
Isolation: Input Output Fully Isolated
Startup: Quick start < 500mS
Protection: Under & over voltage protection
HPF, High brightness, Flicker free

Color & Lighting

LED Colour: 6500K
Lumens: 110Lm/W
Beam angel: 120˚
CRI: >=80%

Operative conditions

Temperature: Ambient temperature
Humidity: up to 80%

Electrical Parameters

Power Range: 20W, 40W
Input Voltage range: AC 100V…265V
Surge Protection: Up to 6kV
Power Factor: >= 0.98
THD: <= 10%

Electrical Connection

Build in Connectors or cable
Input side: Three wire (P~N~E) for 230V AC
Output side: Connect with led

Controls

Dimming mode: No Dimming
Interface: No Interface

Mechanical Construction

ABS housing with acrylic diffuser
Two clamps for surface fitting
Dimension: Refer TDS
Weight: NA

Applications & Examples

Offshore
Tunnel, Cave
Railway Station, Bus Station
Pharma Industries
Chemical Industries

Technical Documents

Product TDS
LM79 report
